CTW130 – Sadara & Jubail Railway Network Project
- Category
- Transportation
- Project type
- Railway Project
- Investor
- Saudi Railway Company (SAR)
- Location
- Jubail, Saudi Arabia
The CTW130 civil and track works project defines the railway connection between Jubail Industrial Cities 1 and 2 (Sadara Petrochemical Facilities) and two ports, King Fahad Industrial Port and Jubail Commercial Port at Jubail, Eastern Province, Saudi Arabia.
- Jubail Railway Network Mainline (Apprx. 41.0 km)
- Line 8 Jubail Commercial Port (JCP) & Marine Loading Yard (9.297 m² + 2.369 m²)
- Line 9 King Fahad Industrial Port (KFIP) & Marine Loading Yard (8.080 m² + 2.729 m²)
- Jubail Railway Network (CTW 130) - SAR North-South Connection Line (CTW 110 & CTW 120) (3.0 km)
- Sadara Sideline & Sadara Loading Yard (6.966 m²)
- SAR Marshalling Yard and Warehouse (28.630 m²)
- Transition Lines (2.0 km)
- Bridges, culverts and other superstructures on piles (59 pcs.)
